Spirits Bottles
500 mL · Flint · Glass · 18.5 mm Bar Top
Compare this spirits bottle by supplier specifications, finish and order format. 500 mL · Flint · Glass · 18.5 mm Bar Top. Request wholesale packaging support from Novvia.
✓
Glass
✓
18.5 mm Bar Top
✓
500 mL
Overview
500 mL Quadra 18.5 mm Bar Top Spirits Bottle — Flint is listed by Saxco under supplier reference 400203173. The supplier specifies height 264.7 mm, diameter 74.4 mm, weight 439.4 g. The stated label panel is 183.3 mm; confirm the current drawing before preparing artwork. Use mold CG27A to distinguish this configuration from similarly named options. Match the exact finish to the proposed closure and confirm filling-line clearance, label dimensions and protective case packing. Confirm the current drawing, sample requirements, order format, availability and delivery with your quote.
✓
Confirm the bottle finish and closure together using the current drawing and production samples.
✓
Check the bottle dimensions and usable label panel against your artwork and equipment.
✓
Use the supplier reference to confirm pack format, availability and delivery with your quote.
Specifications
Capacity
500 mL
Capacity (supplier standard)
17 oz
Material
Glass
Color
Flint
Profile
Quadra
Mold
CG27A
Finish specification
18.5 mm
Finish type
Bar Top
Height
264.7 mm
Diameter
74.4 mm
Weight
439.4 g
Label panel
183.3 mm
Overflow capacity
531 mL
Fill point
27.6 mm
Surface treatment
Tin & Poly
Supplier reference
400203173
Order formats by reference
400203173: Case (12)
Common Uses
Distilled spirits, subject to pack qualification
Liqueurs and specialty spirits, subject to compatibility review
Brand and label development with production samples
How to spec yours
Start with the nominal fill volume and sales format. Confirm the intended fill point and headspace against the supplier drawing; overflow capacity is not the labeled fill volume.
Match the exact bottle finish to its closure. For bar tops, check bore and stopper shank; for threaded finishes, confirm thread profile, cap liner and any tamper-evident band. Test sealing and application with your product and equipment. Closures are separate unless included in the quote.
Review bottle height, diameter or full width and depth, filled weight and case layout against your filling line, shelf and transit packaging. A square, oval or flask profile needs more than one footprint dimension.
Use the current drawing to confirm the usable label panel, seams, taper and decoration area. Test the selected artwork on a sample before committing to production.
Confirm the glass, closure and any tamper-evident component together. Do not infer pressure suitability from shape or glass weight; agree the application and qualification requirements with your packaging specialist.
Share your annual volume, first order, delivery location and launch date. Ask the team to confirm current stock, minimum order, case or pallet configuration and lead time for the exact supplier reference.
Compare
Type
Best For
Key Benefit
Consideration
Round bottle profiles
Projects evaluating a cylindrical bottle footprint
Straightforward diameter comparison for line and case planning
Height, label panel and closure still vary between models
Square, oval and flask profiles
Projects seeking a distinctive shelf profile
Alternative face shapes for label and pack presentation
Confirm full width, depth, orientation and handling from the drawing
Smaller fill volumes
Projects planning 375 mL or 500 mL formats
A different serving or retail format within a brand range
Do not assume the closure or line settings match a 750 mL bottle
Are closures included with the bottle?
+
Specify the closure separately unless your quote expressly includes it. Match bar top stoppers or threaded caps to the exact bottle drawing, then check material compatibility, sealing and application using production samples.
Is the case pack the minimum order?
+
No. The listed case pack describes the supplier packaging format. Confirm the current minimum order, pallet configuration, availability and lead time with your quote.
Can these bottles be used for carbonated drinks?
+
Do not assume pressure suitability from appearance or weight. Confirm the pressure rating and complete bottle-and-closure system with your packaging specialist before selecting glass for a carbonated product.
What information should I send for a quote?
+
Include the supplier reference, fill volume, spirit type, required quantity, closure, label or decoration needs, delivery location and target date. Ask for the latest bottle drawing and a sample for your line review.
Our packaging specialists will help you match the ideal container to your product, storage, and compliance needs. We stock and ship nationwide.
